Automotive Wiring Diagram

by TroneStudio


Auto & Vehicles

free



This application allows you to deal with a problem on the car electrical circuit, including:1. START...

Read more

This application allows you to deal with a problem on the car electrical circuit, including:1. STARTING & CHARGING SYSTEM - BATTERY,IGNITION SWITCH,STARTER MOTOR,GENERATOR & PNP SWITCH CIRCUIT2. ECM (ENGINE CONTROL MODULE) - BATTERY POWER SUPPLY,GROUND,EI SYSTEM & CKP SENSOR CIRCUIT - FUEL PUMP,FUEL CONNECTOR & CMP SENSOR CIRCUIT,INJECTOR & HEATED O2 SENSOR CIRCUIT - MTIA,IAC,SENSOR (MAP,ECT,TP,IAT,KNOCK,ACP,HO2S,O2 & ROUGH ROAD) EGR VALVE,LEGR CIRCUIT & POWER STEERING PRESSURE SWITCH CIRCUIT - EVAP CANISTER PURGE SOLENOID,CMP SENSOR,VGIS,CLUSTER & VSS CIRCUIT - CLUSTER,FUEL PUMP & TCM CIRCUIT - DLC,MIL LAMP & IMMOBILIZER CONTROL CIRCUIT & RON SWITCH CIRCUIT3. TCM (TRANSMISSION CONTROL MODULE) - POWER SUPPLY,GROUND,PNP SWITCH,BRAKE SWITCH & SOLENOID VALVE CIRCUIT - SENSOR (INPUT SPEED,OUTPUT SPEED,TRANSMISSION FLUID TEMP),CLUSTER,DLC,ECM & HOLD MODE SWITCH CIRCUIT - PNP SWITCH & CLUSTER CIRCUIT4. AIR CONDITIONER - AIR CONDITIONER CONTROL SWITCH,BLOWER MOTOR RESISTER & BLOWER MOTOR CIRCUIT - AIR CONDITIONER CONTROL,INTAKE MOTOR SWITCH & AIR CONDITIONER COMPRESSOR CIRCUIT5. FATC (FULL AUTOMATIC TEMPERATURE CONTROL) - BLOWER MOTOR,INTAKE MOTOR,MODE MOTOR,MAX HIGH RELAY & POWER TR CIRCUIT - SENSOR (AMBIENT,INCAR,SUN & WATER),AIR MIX DOOR MOTOR,A/C COMPRESSOR & ECM CIRCUIT6. RADIATOR COOLING FAN CIRCUIT7. HEAD LAMP & HEAD LAMP LEVELING DEVICE (HLLD) CIRCUIT8. ILLUMINATION CIRCUIT - ILLUMINATION CIRCUIT -- W/ DIMMER CONTROL - LAMP (LICENSE PLATE & W/ FRONT / REAR PARKING) CIRCUIT9. FRONT & REAR FOG LAMP CIRCUIT10. HAZARD & TURN SIGNAL LAMP CIRCUIT11. STOP LAMP,CENTER HIGH MOUNT STOP LAMP (CHMSL) & REVERSE LAMP CIRCUIT12. TRUNK OPEN SWITCH,TRUNK LATCH SWITCH,TRUNK ROOM LAMP & HORN CIRCUIT - DUAL HORN - SIGNLE HORN13. LAMPS (MAP & ROOM) CIRCUIT - W/O SUN ROOF & W/O DECAY - W/ SUN ROOF & W/O DECAY14. CLOCK,CIGAR LIGHTER,ASHTRAY ILLUM.LAMP & EXTRA POWER JACK CIRCUIT - M/T - A/T15. CHIME BELL,SEAT BELT & KEY REMIND SWITCH CIRCUIT16. WIPER CIRCUIT - W/O RAIN SENSOR & AIR CONDITIONER,FATC - W/ RAIN SENSOR & AIR CONDITIONER,FATC17. REAR WINDOW DEFROSTER & OSRV MIRROR HEATING SYSTEM CIRCUIT18. ELECTRIC OSRV (OUTSIDE REAR VIEW) MIRROR CIRCUIT19. FOLDING MIRROR UNIT CIRCUIT20. POWER WINDOW CIRCUIT - ONLY FRONT POWER WINDOW CIRCUIT - FRONT & REAR POWER WINDOW CIRCUIT21. CENTRAL DOOR LOCKING SYSTEM CIRCUIT22. CLUSTER - TEMPERATURE GAUGE,TACHOMETER,FUEL GAUGE,ODDOMETER,SPEEDOMETER & FUEL WARNING LAMP CIRCUIT - WARNING (MIL,ABS,TCS,PARKING BRAKE & CHARGING) LAMP CIRCUIT - WARNING (SSPS,AIR BAG,OIL PRESSURE & SEAT BELT) LAMP & HOLD MODE CIRCUIT - INDICATOR LAMP (FRONT & REAR FOG) & DOOR OPENING WARNING LAMP CIRCUIT - INDICATOR LAMP (TURN SIGNAL,HIGH BEAM & HAZARD) & ILLUMINATION LAMP CIRCUIT23. AUDIO CIRCUIT - W/O RDS - W/ RDS24. ABS (ANTI LOCK BRAKE SYSTEM) - POWER SUPPLY,WHEEL SPEED SENSOR & BRAKE SWITCH CIRCUIT - OIL FEEDING CONNECTOR,WARNING (ABS,TCS & BRAKE) LAMP & DLC CIRCUIT25. AIR BAG (SDM: SENSING & DIAGNOSTIC MODULE) CIRCUIT26. SUN ROOF CIRCUIT27. SSPS (SPEED SENSITIVE POWER STEERING) CIRCUIT28. IMMOBILIZER SYSTEM CIRCUIT29. ANTI THEFT CONTROL SYSTEM CIRCUITdownload for free, may be useful
